General Product Selection Guid for Fluids
| Application | AF | AFX | AFR | CAT | CTV | F | FR | FP | FPR | ST | STE | TL | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Water Lines | | | ||||||||||||
| Freeze Protection | Condensate Lines | | | |||||||||||
| Pumps | | | | |||||||||||
| Scald Protection | | | ||||||||||||
| Eye Wash Stations | Freeze Protection | | | |||||||||||
| Scald Protection | | | ||||||||||||
| Glycol Control | | |||||||||||||
| Heat exchanger Control | | | | | | |||||||||
| Unit Heater Control | | |||||||||||||
| Over Temperature Control | | | ||||||||||||
| Process Heating Coils | | | ||||||||||||
| Safety Showers | Freeze Protection | | | |||||||||||
| Scald Protection | | | ||||||||||||
Ogontz Works For You
Energy Conservation in Steam Tracing Lines: TL ambient sensing valve controls the flow of steam to tracing lines, shutting off flow automatically when the ambient temperature rises above the desired level. CTV/CAT and OPT trap eliminate live and flash steam losses.
TANK REGULATION: ST/STE valve with optional fittings shown inserted into a thermal well for control of product temperature in a tank.
Freeze Protection: Type F valve provides positive freeze protection by draining the system when fluid temperature approaches a critical temperature.
Freeze and Scald Protection for an Emergency Shower: Type FP and FPR valves provide freeze and scald protection for emergency shower and eyewash stations.
ENCLOSURE TEMPERATURE CONTROL IEV valve senses enclosure temperature and automatically regulates flow of steam to maintain temperature within ±3°F.
